Removal and Installation Procedures
Maintenance
6Ć50
CH3 OUT  J1201
AUXILIARY TRIGGER  J1550
MAIN TRIGGER  J1000
DELAY TRIGGER  J1001
EMI GASKET
Figure 6Ć23:ăRear Chassis Removal
