Tektronix TDS 600B User Manual

Operating Interface Maps
2–4
TDS 500C, TDS 600B, & TDS 700C User Manual
Front Panel Map — Right Side
Hardcopy, page 3–164
File System, page 3–160
Autoset, page 3–8
Help, page 3–181
Status, page 3–179
Selecting Channels,
page 3–11
Horizontal Controls,
page 3–19
Acquisition Modes, page 3–29
Cursor Measurements, page 3–126
Triggering, page 3–63
Delay Triggering, page 3–106
Edge Triggering, page 3–72
Logic Triggering, page 3–76
Pulse Triggering, page 3–89
Comm Triggering, page 3–103
Color, page 3–44
Display Settings,
page 3–38
Remote
Communication,
page 3–174
Vertical Controls,
page 3–15
Measurement System, page 3–114
Saving and Recalling
Setups, page 3–151
Saving and Recalling
Waveforms, page 3–154
File System, page 3–160
Waveform Math,
page 3–188
Zoom, page 3–49
Probe Calibration,
page 3–143
Ground
Cursor
Measurements,
page 3–126
InstaVu,
page 3–55
(TDS 500C
& TDS 700C
models only)
