Product Description

1–2

TDS 684A, TDS 744A, & TDS 784A User Manual

Table 1–1: Key Features of the TDS Oscilloscopes (Cont.)

Feature TDS 784ATDS 744ATDS 684A

Trigger modes Include: edge, logic, and pulse. Video trigger, with option 05, modes

include:

NTSC, SECAM, PAL, HDTV, and FlexFormat.

Storage 1.44 Mbyte, 3.5 inch, DOS 3.3-or-later floppy disk.

NVRAM storage for saving waveforms, hardcopies, and setups

I/O Full GPIB programmability.

Hardcopy output using GPIB, RS-232, or Centronics ports

Product Specification

The product specification is found in the technical reference TDS 684A,

TDS 744A, & TDS 784A Performance Verification and Specifications that is

shipped as a standard accessory with the TDS Oscilloscope.
