CAUTION. Using the P6243 or P6245 Active Probe to measure signals greater
than ±40 volts may damage the probe. Using the P6158 Voltage Divider Probe to
measure signals greater than ±22 V
RMS
may damage the probe.
Be sure to choose the proper input coupling and impedance for the probe or other
cabling you use to couple signals to your oscilloscope. You should read Input
Impedance Considerations on page 3–8 for information needed to ensure proper
coupling of your input signals.
Putting into Service
To learn how to install, access the front panel, power on, do a self test, and
power off the oscilloscope, do the following procedures:
To properly install and power on the oscilloscope, do the following steps:
1. Be sure you have the appropriate operating environment. Specifications for
temperature, relative humidity, altitude, vibrations, and emissions are
included in the TDS 500D, TDS 600B, & TDS 700D Technical Reference
(Performance Verification and Specifications) manual (Tektronix part
number 071-0135-xx).
2. Leave space for cooling. Do this by verifying that the air intake and exhaust
holes on the sides and bottom of the cabinet are free of any airflow obstruc-
tions. Leave at least 5.1 cm (2 inches) free on each side.
WARNING. To avoid electrical shock, be sure that the power cord is disconnected
before checking the fuse.
3. Check the fuse to be sure it is the proper type and rating (see Figure 1–1).
You can use either of two fuses. Each fuse requires its own cap (see
Table
1–2). The oscilloscope is shipped with the UL approved fuse installed.
4. Check that you have the proper electrical connections. The oscilloscope
requires 100 to 240 VAC
RMS
, continuous range, 45 Hz to 440 Hz, and may
require up to 300 W.
