Command Descriptions
TDS200/1000/2000 Series Oscilloscope Programmer Manual
2−1 19
FALL (TDS1000 and TDS2000 series, or TDS200 series with a
TDS2MM measurementmodule only) is the fall time between 90%
and 10% of the first falling edge of the waveform. Falling edge must
be displayed to measure. The oscilloscope automatically calculates
the 10% and 90% measurement points.
PWIdth (TDS1000 and TDS2000 series, or TDS200 series with a
TDS2MM measurementmodule only) is the positive pulse width
between the first rising edge and the next falling edge at the
waveform 50% level. Rising and falling edges must be displayed to
measure. The oscilloscope automatically calculates the 50%
measurement point.
NWIdth (TDS1000 and TDS2000 series, or TDS200 series with a
TDS2MM measurementmodule only) is the negative pulse width
between the first falling edge and the next rising edge at the
waveform 50% level. Falling and rising edges must be displayed to
measure. The oscilloscope automatically calculates the 50%
measurement point.
NONE disables the measurement specified by <x>.
MEASUrement:MEAS3:TYPe CRMS
specifies MEAS3 to calculate the true Root Mean Square value.
MEASUrement:MEAS<x>:UNIts? (Query Only)
Returns the units for the oscilloscope measurement specified by
MEASUrement:MEAS<x>:TYPe.
Measurement
MEASUrement:MEAS<x>:UNIts?
<QString> returns V" for volts, s" for seconds, Hz" for Hertz, or
a null string if MEASUrement:MEAS<x>:TYPe is set to NONE.
Examples
Group
Syntax
Returns
