Specications
Data Logging S
ystem C haracteristics
NOTE. This software feature directs the oscilloscope to automatically collect
data over a period of time. After you congure the trigger conditions to use,
you can use the data logging menu to set up the oscilloscope so that it will save
all of the triggered waveform to a USB memory device, within a time duration
that you have set.
Table 1-10: Data logging system characteristics
Characte
ristic
Descripti
on
Duration The time period.
30 min, 1 h
our, 1.5 hour, 2 hour, 2.5 hour, 3 hour, 3.5 hour, 4 hour, 4.5 hour, 5 hour, 5.5 hour, 6 hour, 6.5
hour, 7 hour, 7.5 hour, 8 hour.
Source The signal source which you want to save the w aveform.
Channel 1, Channel 2, Channel 3, Channel 4, Math
Select Folder The le folder where you save the waveform data.
You can
create the new folder or change the existing folder as the folder where you want to save the
waveform data.
Limit
Testing System Characteristics
NOTE. This software feature directs the oscilloscope to monitor an active input
signal against a template and to output pass or fail results by judging whether
the input signal is within the bounds of the template.
Table 1-11: Limit testing system characteristic s
Characteristic Description
Source
The signal source which you want to do the limit testing.
Channel 1, Channel 2, Channel 3, Channel 4, Math
Compare Ref Channel The reference channel # where the template is saved.
R
efA, RefB, RefC, RefD. The limit testing system will compare the source signal with this template.
R
un/Stop
T
o enable or disable the limit testing function.
Run, Stop.
Template Setup You can use this menu item to set up a limit test waveform template. The template is the mask signal that
you dene as the boundary to compare with the input source signal. You can create the template from
internal or external waveforms with specic horizontal and vertical tolerances.
Source The location of the signal source that is used to create the limit test template.
Channel 1, Channel 2, Channel 3, Channel 4, Math
1–14 TDS2000C Series Oscilloscope Service Manual
