Replaceable Parts
Table 28: Repla
ceable parts list, 2-channel models
Figure
and
index
no.
Tektronix
part no.
Serial
no.
effective
Serial
no.
discont'd Qty. Name and description
8-1
2-CHANNEL MODELS
202-0436-00 1
FRONT CASE ASSY; COVER, W/FEET, TDS1001C-EDU, TDS1002C-EDU,
TDS1012C-EDU, TDS2001C, TDS2002C, TDS2012C, TDS2022C
850-0156-00 1
FRONT CASE ASSY; COVER, W/FEET, TDS2001C, TDS2002C, TDS2012C, TDS2022C
-1
850-0173-00 1
FRONT CASE ASSY; COVER, W/FEET, TDS1001C-EDU, TDS1002C-EDU,
TDS1012C-EDU,
-2 366-0863-00 1
ASSEMBLY, KNOB; 0.685 DIAMETER
-3 366-0862-00 1
ASSEMBLY, KNOB; 0.470 DIAMETER
335-2308-00 1
MARKER, IDENTIFICATION 2-CH LANGUAGE, FRENCH
335-2309-00 1
MARKER, IDENTIFICATION 2-CH LANGUAGE, ITALIAN
335-2310-00 1
MARKER, IDENTIFICATION 2-CH LANGUAGE, GERMAN
335-2311-00 1
MARKER, IDENTIFICATION 2-CH LANGUAGE, SPANISH
335-2312-00 1
MARKER, IDENTIFICATION 2-CH LANGUAGE, JAPANESE
335-2313-00 1
MARKER, IDENTIFICATION 2-CH LANGUAGE, PORTUGUESE
335-2314-00 1
MARKER, IDENTIFICATION 2-CH LANGUAGE, SIMPLIFIED CHINESE
335-2315-00 1
MARKER, IDENTIFICATION 2-CH LANGUAGE, TRADITIONAL CHINESE
335-2316-00 1
MARKER, IDENTIFICATION 2-CH LANGUAGE, KOREAN
-4
335-2317-00 1
MARKER, IDENTIFICATION 2-CH LANGUAGE, RUSSIAN
-5
260-2904-70 1
SWITCH, KEYPAD; ELASTOMERIC, FRONT PANEL, 2-CH COLOR, BONDED
-6 211-1272-00 9
SCREW, MACHINE; 6-32 X 0.250, PNH, STL, ZNPL, T-15 TORX DR
-7
870-0188-02 1
CIRCUIT BD ASSY; FRONT PANEL BOARD 2-CH, 389- 3835-01 WIRED
-8 441-2454-03 1
CHASSIS ASSY; 2 CHANNEL; SAFETY CONTROLLED
870-0877-00
C030000
1
CIRCUIT BD ASSY; M AIN, 2-CH, 40 MHZ, TESTED & CONFIGURED, COLOR,
389-4333-00 WIRED; TDS1001C-EDU
870-0878-00
C030000
1
CIRCUIT BD ASSY; M AIN, 2-CH, 60 MHZ, TESTED & CONFIGURED, COLOR,
389-4333-00 WIRED; TDS1002C-EDU
870-0879-00
C030000
1
CIRCUIT BD ASSY; MAIN, 2-CH, 100 MHZ, TESTED & CONFIGURED, COLOR,
389-4333-00 WIRED; TDS1012C-EDU
870-0870-00
C030000
1
CIRCUIT BD ASSY; M AIN, 2-CH, 50 MHZ, TESTED & CONFIGURED, COLOR,
389-4333-00 WIRED; TDS2001C
870-0871-00
C030000
1
CIRCUIT BD ASSY; M AIN, 2-CH, 70 MHZ, TESTED & CONFIGURED, COLOR,
389-4333-00 WIRED; TDS2002C
870-0872-00
C030000
1
CIRCUIT BD ASSY; MAIN, 2-CH, 100 MHZ, TESTED & CONFIGURED, COLOR,
389-4333-00 WIRED; TDS2012C
-9
870-0873-00
C030000
1
CIRCUIT BD ASSY; MAIN, 2-CH, 200 MHZ, TESTED & CONFIGURED, COLOR,
389-4333-00 WIRED; TDS2022C
-10 210-1039-00 3
WASHER, LOCK; 0.521 ID, INT, 0.025 THK, STEEL, ZINC FINISH
-11 220-0265-00 3
NUT, PLAIN, HEX; 0.5-28 X 0.625 HEX, BRS CD PL
-12 131-6417-00 1
CONTACT, ELEC; GROUNDING, 0.600 L X 0.250 W X 0.220 D, ELECTROLESS NICKEL
PLATE
-13 131-6521-00 1
CONTACT, ELEC; EMI, CLIP-ON, 0.38 L X 0.460 W (2 CONTACTS) X 0.45 HIGH,
ELECTROLESS NICKEL PLATE
90 TDS2000C and TDS1000C-EDU Series Oscilloscope Service Manual
