Maintenance
Required Tools
Use the followi
ng tools to remove and replace all modules in the oscilloscope:
Torque-limiting screwdriver, long shank, 12 in-lb (1.3 N ·m) range with Torx®
T-15 tip; if yo
u use a magnetic screwdriver with interchangeable bits, the T-15
bit must b e a long bit, at least 5 cm (2 in) overall length
Torque-lim
iting screwdriver with Torx T-8 bit
5/8 inch d eep socket with wide center hole (S·K Hand Tool Corp., S-K
#40820, or e
quivalent)
Torque wrench to 4 0 in-lb (4.5 N·m)
Screwdriver with 1/4 inch flat blade
Pliers (all-purpose and needle-nose)
Sharp knife (X-ACTO®knife or equivalent)
3M Electrical Tape 92 with 1-mil polyimide Kapton backing, temperature
rated 180 °C, UL510 Flame Retarded
Rear Feet
You w il
l need a flat-blade screwdriver to remove the rear feet.
Refer to the exp l od ed view diagram. (See page 9 6.)
Removal.
1. Place the oscilloscope face down on a so ft surface such as an anti-static mat.
2. Use a flat-blade screwdriver to pry out the fo ot, or twist th e foot as you are
removing it so that it disengages from the guides. Use care not to mar the
surface of the rear case.
Installation.
1. Place the oscilloscope face down on a so ft surface such as an anti-static mat.
2. Align the slots of the rear foot with the guides in the rear case and p ress the
foot in.
56 TDS2000C and TDS1000C-EDU Series Oscilloscope Service Manual
