Tektronix TDS2014C Service Manual

Performance Verification
This chapter contains performance verification procedures for the specifications
marked with the check mark. The following equipment, or a suitable equivalent,
is required t
o complete these procedures.
Required Equipment
Table 12: P
erformance verification
Descripti
on
Minimum re
quirements
Examples
DC Voltage
Source
17.5mVto7
V, ±0.5% accuracy
Leveled S
ine Wave Generator
50 kHz and
200 MHz, ±3% amplitude accuracy
Time Mark
Generator
10 ms period, ±10 ppm accuracy
Wavetek 91
00 Universal Calibration
System with Os cilloscope Calibration
Module (Option 250)
Fluke 550
0A Multi-product Calibrator with
Oscilloscope Calibration Option (Option
5500A-SC)
50Ω BNC Cable BNC male to BNC male, ≈ 1 m (36 in) long
Tektronix part number 012-0482-XX
50Ω BNC Cable BNC male to BNC male, ≈ 25 cm (10 in) long
Tektronix part number 012-0208-XX
50Ω Feedthrough Termination BNC male and female connectors
Tektronix part number 011-0049-XX
Dual Banana to BNC Adapter Banana plugs to BNC female
Tektronix part number 103-0090-XX
BNC T Adapter BNC male to dual BNC female connectors
Tektronix part number 103-0030-XX
Splitter, Power Frequency range: DC to 4 GHz.
Trac
king: >2.0%
Tektronix part number 015-0565-XX
Ada
pter (four required)
Mal
e N -to-female BNC
Tektronix part number 103-045-XX
Adapter
Fem
ale N -to-male BNC
Tektronix part number 103-0058-XX
Leads, 3 Black
St
acking Banana Plug Patch Cord, ≈ 45 cm
(18 in) long
Po
mona #B-18-0
Le
ads, 2 Red
Stacking Banana Plug Patch Cord, ≈ 45 cm
(18 in) long
Pomona #B-18-2
TDS2000C and TDS1000C-EDU Series Oscilloscope Service Manual 27
