Tektronix TDS2024C

Adjustment Procedures
Table 15: Adjustment steps (cont.)
Input Setup diagram Step number Signal Signal sou rce setting
35
Sinewave Generator, 50 Ω
5kHz,1V
p-p
36
Sinewave Generator, 50 Ω
1 MHz, 100 mV
p-p
37
Sinewave Generator, 50 Ω
1MHz,1V
p-p
38
Sinewave Generator, 50 Ω
50 kHz, 1 V
p-p
39
Sinewave Generator, 50 Ω
20 MHz, 1 V
p-p
40
Sinewave Generator, 50 Ω
BWL, 25 mV
p-p
41
Sinewave Generator, 50 Ω
BWL, 50 mV
p-p
42
Sinewave Generator, 50 Ω
BWL, 100 mV
p-p
43
Sinewave Generator, 50 Ω
BWL, 250 mV
p-p
44
Sinewave Generator, 50 Ω
BWL, 500 mV
p-p
45
Sinewave Generator, 50 Ω
BWL, 1 V
p-p
46
Sinewave Generator, 50 Ω
5kHz,2.5V
p-p
47
Sinewave Generator, 50 Ω
1MHz,2.5V
p-p
48
Sinewave Generator, 50 Ω
50 kHz, 2.5 V
p-p
49
Sinewave Generator, 50 Ω
20 MHz, 2.5 V
p-p
50
Sinewave Generator, 50 Ω
BWL, 2.5 V
p-p
51
Sinewave Generator, 50 Ω
BWL, 5 V
p-p
Sinewave
generator
52
Sinewave Generator, 50 Ω
BWL, 1.6 V
p-p
Ch 1
Edge 53
Edge, 50 Ω.
1 kHz, 0 to -800 mV
54
Sinewave Generator, 50 Ω
5kHz,1V
p-p
55
Sinewave Generator, 50 Ω
1 MHz, 100 mV
p-p
56
Sinewave Generator, 50 Ω
1MHz,1V
p-p
57
Sinewave Generator, 50 Ω
50 kHz, 1 V
p-p
58
Sinewave Generator, 50 Ω
20 MHz, 1 V
p-p
59
Sinewave Generator, 50 Ω
BWL, 25 mV
p-p
60
Sinewave Generator, 50 Ω
BWL, 50 mV
p-p
61
Sinewave Generator, 50 Ω
BWL, 100 mV
p-p
62
Sinewave Generator, 50 Ω
BWL, 250 mV
p-p
63
Sinewave Generator, 50 Ω
BWL, 500 mV
p-p
64
Sinewave Generator, 50 Ω
BWL, 1 V
p-p
65
Sinewave Generator, 50 Ω
5kHz,2.5V
p-p
66
Sinewave Generator, 50 Ω
1MHz,2.5V
p-p
67
Sinewave Generator, 50 Ω
50 kHz, 2.5 V
p-p
68
Sinewave Generator, 50 Ω
20 MHz, 2.5 V
p-p
69
Sinewave Generator, 50 Ω
BWL, 2.5 V
p-p
Ch 2 Sinewave
generator
70
Sinewave Generator, 50 Ω
BWL, 5 V
p-p
46 TDS2000C and TDS1000C-EDU Series Oscilloscope Service Manual
