Tektronix TDS2024C

Adjustment Procedures
Table 15: Adjus
tment steps
Input Setup diagram Step num ber Signal Signal source setting
1
DC Voltage 1
0.0 V
2
DC Voltage 1
-20.0 V
3
DC Voltage 1
-2.0 V
4
DC Voltage 1
-1.6 V
5
DC Voltage 1
-1.2 V
6
DC Voltage 1
-0.8 V
7
DC Voltage 1
-0.4 V
8
DC Voltage 1
-0.32 V
9
DC Voltage 1
-0.2 V
10
DC Voltage 1
-0.16 V
11
DC Voltage 1
-0.08 V
12
DC Voltage 1
-0.04
V
13
DC Voltage 1
-0.0
3V
14
DC Voltage 1
-0.0
2V
15
DC Voltage 1
-0.
015 V
16
DC Voltage 1
0.0
15 V
17
DC Voltage 1
0.
02 V
18
DC Voltage 1
0.
03 V
1
9
DC Voltage 1
0
.04 V
2
0
DC Voltage 1
0
.08 V
21
DC Voltage 1
0.16 V
22
DC Voltage 1
0.2 V
23
DC Voltage 1
0.32 V
24
DC Voltage 1
0.4 V
25
DC Voltage 1
0.8 V
26
DC Voltage 1
1.2 V
27
DC Voltage 1
1.6 V
28
DC Voltage 1
2.0 V
29
DC Voltage 1
20.0 V
Ch 1 through
Ch x
DC voltage 1
30
DC Voltage 1
0.0 V
31
DC Voltage 2
-5.0 V
32
DC Voltage 2
-1.0 V
33
DC Voltage 2
1.0 V
Ext Trig
DC voltage 2
34
DC Voltage 2
5.0 V
TDS2000C and TDS1000C-EDU Series Oscilloscope Service Manual 45
