Audio Performance Verification
Instrument Digital
FUNCTION - PEAK & S/N
Meas Mode PK abs
Intv Time 0.5000s
Unit
s
Reference GEN TRACK
Filter JITTER wtd
SPEAKER - OFF
10. Allow the jitter reading to settle for a few seconds.
11. Check for a typical Jitter Peak absolute reading of less than 3.5 ns over an
interval of at least 5 seconds, and record the Pass/fail result in the test record.
12. Move the cable to each of the remaining AES B I/O connectors and repeat
steps 10 and 11 for each AES B I/O connector.
13. Disconnect the test setup.
AES Audio Level Meter
Accuracy Over Frequency
This test measures AES level meter accuracy over the audio frequency range.
Typical Operation Check. This test checks for typical operation. Typical values
are not guaranteed characteristics and are listed in the test record as Pass / fail.
Waveform Rasterizers Specifications and Performance Verification 115
