Specifications
Table 40: Embedded audio extraction and monitoring on status bar (Option AD) (cont.)
Characteristic Performance requirement Reference information
Channel Numbering Channel numbers per SMPTE 272M and
SMPTE 299M ( 1 through 16) will be correctly
shown on all displays.
Audio Levels
Bars display signals up to 0 dBFS.
Must not exceed maximum power
specification on analog outputs. Configure
output attenuation if necessary.
Table 41: Analog audio inputs (Option AD)
Characteristic Performance requirement Reference information
Number of Channels Provides up to two sets of six channels of
profess
ional balanced differential inputs
for each video input, 12 channels total.
Input Connector
Balanc
ed, unterminated through rear
panel connector.
Level M
eter Accuracy over Frequency
± 0.5dB from 20 Hz to 20kHz 0 to
–40dBFS sine wave, Peak Ballistic mode.
Cross Talk (typical) ≤–80 dB, typically ≤ –90 dB from 20 Hz to
20 kHz
, inputs driven from <600 Ω source
impedance.
Defined as the displayed bar level in
any ch
annel that results from a full scale
signal on a different input pair in that
input.
Maximum Input Levels +24 dBu
Must not exceed max power specification
on a
nalog outputs. Configure output
attenuation if necessary.
Sampling Resolution
24 b
its at 48 kHz.
Input Impedance (typical) 24 kΩ , balanced.
Un
balanced input impedance is typically
18 kΩ .
Off Isolation (typical) ≤–80 dB, from 20 Hz to 20 kHz. Unused
input terminated by <600 Ω source
i
mpedance.
Table 42: Analog audio outputs (Option AD)
Characteristic Performance requirement Reference information
Audio Modes
Balanced: Provide a full-scale output
of 24 dBu. This mode is intended for
professional balanced applications.
Unbalanced: Intended to drive the
unbalanced inputs of consumer amplifiers,
in which case one side of the line must be
grounded.
Outputs are to drive line level inputs. Not
intended to drive speakers directly.
Waveform Rasterizers Specifications and Performance Verification 2 7
