Table 42: Analog audio outputs (Option AD) (cont.)
Characteristic Performance requirement Reference information
Audio Sources
The channels routed to the line outputs may
include:
Embedded audio source
AES audio source
Analog audio source
Number of Channels
Provides up to eight channels.
Output Connections
Balanced, unterminated through rear panel
connector.
Maximum Output Levels
Balanced +24 dBu ± 0.5 dB When grounding one output to achieve
unbalanced mode, the other output will
be driven to a larger amplitude You may
reduce the level by adding attenuation in
the configuration m enu. Do not exceed
maximum rated power in either mode.
Unbalanced +10 dBV ± 0.5 dB
Input to Output Gain
0 dB to –120 dB in 0.5 dB s teps.
Digital Input to Analog Output Gain
Accuracy over frequency
± 0.5 dB, 20 Hz to 20 kHz, 0 to –40 dBFS,
20 or 24 bit input.
Analog Input to Analog Output
Gain Accuracy over frequency
± 1 dB, 20Hz to 20 kHz, 24 dBu to –16 dBu.
Output Impedance (typical) 50 Ω , balanced.
Intended to drive a high impedance load.
Drivers are capable of driving a minimum
load impedance of 300 Ω but may overheat.
Do not exceed the maximum rated power.
Digital Input to Analog Output
Distortion (THD+N) (typical)
≤ 0.02% from full scale to –30 dBFS,
20 Hz to 20 kHz.
Analog Input to Analog Output
Distortion (THD+N) (typical)
< 0.05% from full scale to –30 dBFS, 20 Hz to
20 kHz.
Analog or Digital Input to Analog
Output Cross-talk (typical)
< –82 dB 20 Hz to 20 kHz 24 dBu or 0 dBFS
input.
< –100 dB 20 Hz to 2 kHz 24 dBu or 0 dBFS
input.
Output Power Capability (typical) Capable of continuously driving a –10 dBFS
sine wave into 600 Ω or –13 dB into 300 Ω .
This is 25 mW RMS in the load per output
pair. Live audio may reach full voltage level
as long as duty cycle is such that the RMS
power is less than 25 mW averaged over
any 10 second period. Exceeding this limit
at high ambient temperature may cause the
output circuit to overheat and damage the
instrument.
