12.3 Operation and alarm indication
12.3.1 RUN mode
In RUN mode, the display will show the current status:
Current status
Description
User present
When user is detected. The sash drive is inhibited, tiptronic
and manual drives are enabled.
XX Seconds to close
When user is not detected, the sash will close following the
countdown delay time.
Sash Closing
Displayed when the sash is driving closed, for example
tiptronic, auto-close, footswitch or pushbutton.
Sash Closed
When the user is not detected and the sash has closed. The
keypad backlight is dimmed.
XX Seconds to open
When the user is detected, the sash opens, following the
countdown delay time. Auto-open is enabled.
Sash Opening
Displayed when the sash is driving open, for example auto-
open, tiptronic, footswitch or pushbutton.
User Manual Move
Displayed when the sash is manually opened or closed.
Sash Inhibited
Displayed when the tilt switch input is open. The drive is
inhibited until the tilt switch is closed.
Sash Disabled
Displayed when the sash drive has been disabled in the
menu settings.
Sash Locked
Displayed when the sash is at or above the calibrated lock
position.
