Teldat M2 User Manual

None Interface is either unavailable, not installed, or not registered.
The following figure shows the router's WAN-2 LED indicators:
Fig. 4: WAN-2 LEDs
WAN-2 2.5G Ethernet LED indicators
LED Description
Yellow
- Steady: 10/100M link established.
- Blinking: Transferring data.
Yellow+Green - Steady: 1000M link established.
- Blinking: Transferring data
Green - Steady: 2.5G link established.
- Blinking: Transferring data
None Interface is either unavailable, not installed, or not registered.
The following figure shows the router's Ethernet switch LED indicators:
Fig. 5: Switch LEDs
Switch LED indicators
LED Description
Yellow Connected to 10/100 M:
- Steady: Not transferring data.
- Blinking: Transferring data.
Yellow + Green Connected to 1000 M:
- Steady: Not transferring data.
- Blinking: Transferring data.
3 Components and Power Supply Teldat S.A.
6 Teldat M2/M2L

Teldat M2 Specifications

General

Brand	Teldat
Model	M2
Category	Network Router
Language	English
