Teldat M8-Smart User Manual

- WAN Connections on page 14
- WAN Base-T Connector on page 29
- WAN Base-T Interface on page 31
E Eth WAN-1 SFP.
For more information about the SFP interface, refer to:
- WAN Connections on page 14
- WAN SFP Connector on page 29
- WAN SFP Interface on page 31
F Eth WAN-2 Base-T. WAN Gigabit Ethernet.
For more information about the WAN interface, refer to:
- WAN Connections on page 14
- WAN Base-T Connector on page 29
- WAN Base-T Interface on page 31
G Eth WAN-2 SFP.
For more information about the SFP interface, refer to:
- WAN Connections on page 14
- WAN SFP Connector on page 29
- WAN SFP Interface on page 31
H Aux. Provides access to the M8-Smart local console for configuration and monit-
oring purposes.
For more information about the Aux connector, refer to:
- Connecting for Configuration on page 17
- Configuration Connector on page 30
- Configuration Interface on page 35
I SIM Card 1-2. Slot where you can insert the SIM cards for the G modules.
Refer to Installing the SIM card on page 18 for more information about SIM install-
ation.
J On/Off switch.
K Power source connection (PSU).
Refer to Power Source on page 12 for more information about Power connection
and Power Supply on page 35 for power specifications applicable to theM8-Smart
device.
L LED S (Status). Refer to LEDs on page 5 for more information.
M LED PWR (Power). Refer to LEDs on page 5 for more information.
N Functional earthing. Usually disconnected.
3 Components and Power Supply Teldat S.A.
8 M8-Smart

Teldat M8-Smart Specifications

General

Brand	Teldat
Model	M8-Smart
Category	Network Router
Language	English
