1-2. Preparation and Precaution
a. Connect one of the end 25-pin interface (program) cable with the
RS232 port on PC/Laptop. (Note: it isn’t the PRINT port.) Using
the adapter or extending wire cable if necessary. The other end of
the 6-pin interface (program) cable will be connected with the
Transmitter or Receiver when reading and writing the data.
b. Make sure the power supplied to the Transmitter and Receiver has
been switched off before the interface (program) cable is
connected with. .
c. Click the function block to select the required function when the
arrow cursor becomes a hand-like icon. In addition, it isn’t
available if the function block is shown as an icon in gray.
d. Select the correct COM PORT when using the software program
on PC or Laptop at first time, for instance, COM 1 or COM 2.
e. Click the left button on the mouse to select the required function
and don’t forget to write it to the Transmitter or Receiver to update
the data, or save it in a disk for keeping in file.
f. Do not remove the interface (program) cable during software
program setting.
10
Chapter 5. Software Instruction
1-1. Click “start” go to “program” and select “F21-E1 SERIAL SETUP
PROGRAM (CRYSTAL)” and click “F21-E1 SERIAL SETUP
PROGRAM” to enter the software program.
To Next Page
