Fire Control Panel MAG2/4 - User Manual 11
• Press RESET:
The SOUNDER FAULT/DISABLE and ENABLE/
DISABLE LEDs light up permanently.
At this step the sounders are disabled.
You can exit the sounder disabling mode also by pressing the “TEST/ SCROLL” button,
as in that case the you reject the procedure.
Z To enable the sounders:
• Press ENABLE/ DISABLE:
DISABLE/ ENABLE LED blinks.
The ZONE 1 yellow LED blinks if ZONE 1 is en-
abled and lights permanently if ZONE 1 is disabled.
• Press TEST/ SCROLL, until
you reach the last zone in the
system:
The SOUNDER FAULT/DISABLE LED lights up
permanently.
• Press ENABLE/ DISABLE:
The SOUNDER FAULT/DISABLE LED will start
blinking.
• Press RESET: At this step the sounders are enabled.
You can exit the sounder enabling mode also by pressing the “TEST/ SCROLL” button,
as in that case the you reject the procedure.
8.2 “One man” Zone Testing
The “One Man” Test mode gives the installer the possibility to test the efciency of the
system - whether the detectors react to smoke, heat, etc.
Z To do “One Man” Test of a zone:
• Press TEST/ SCROLL:
µP Fault and General Fault LEDs light off. All other
system indication LEDs light on permanently.
• Press TEST/ SCROLL again:
The TEST LED and ZONE 1 yellow LED start
blinking.
ZONE 1 is in test mode. Test a detector from this
zone whether it react to smoke, heat, etc.
• Press TEST/ SCROLL again to
continue with the system testing:
TEST LED will continue blinking.
The ZONE 1 yellow LED lights out (the zone is
not longer in test mode). The ZONE 2 yellow LED
blinks in yellow.
ZONE 2 is in test mode. Test a detector from this
zone whether it react to smoke, heat, etc.
Continue the system testing by pressing the “TEST/ SCROLL” button. The exit from the
“One Man” Test mode is automatic after the end of the test procedure in the last Zone 4,
or at any time by pressing “RESET” button.
