Fire Control Panel MAG8 - Installation and Operation Manual
1. Using the MAG8 Controls
LED indication for the status of
the zones - see item 1.2.
LED indication for
the technical faults
in the system - see
item 1.3.
This indication is not
visible from the user.
To examine the
faults in the system
the engineer has
to remove the front
cover of the box.
LED indication for the sys-
tem status - see item 1.4.
Switch for changing over
between Access Levels 1
and 2 - see item 1.6.
Buttons for programming and
operation - see item 1.5.
