13
21
660Hz 0.15s ON/0.15s OFF
22
510Hz, 0.25s/ 610Hz, 0.25s
23
800/1000Hz 0.5s each (1Hz)
24
250Hz - 1200Hz @ 12Hz
25
500Hz - 1200Hz @ 0.33Hz
26
2400Hz - 2900Hz @ 9Hz
27
2400Hz - 2900Hz @ 3Hz; 2500Hz (main sound frequency)
28
800Hz - 970Hz @ 100Hz
29
800Hz - 970Hz @ 9Hz
30
800Hz - 970Hz @ 3Hz
31
800Hz, 0.25s ON/1s OFF
32
600Hz – 1100Hz, 2.6s/0.4s OFF
Confirm the setting with ENTER button – the exit of the menu is automatic.
14.4 Menu for Setting the Tone Volume
The menu is available only for Natron sounders. In the menu the installer sets the tone volume of
the sounder.
To set the tone volume, from the main menu scroll to 4. DEVICE SETUP and select a sounder
number with the arrow buttons. Press ENTER. Select menu 3. VOLUME and press ENTER
button. There two setting, as the currently set is displayed on the screen. The setting is changed
with pressing up/down arrow buttons:
- HIGH – set by default.
- LOW.
Confirm the setting with ENTER button – the exit of the menu is automatic.
14.5 Menu for Setting the Mode of Sounder
The menu is available only for sounders. In the menu the installer sets the mode of operation.
Attention! The setting of this menu does not affect on the signalization in finding device
procedure.
To set the mode of operation, from the main menu scroll to 4. DEVICE SETUP and select a
sounder number with the arrow buttons. Press ENTER. Select menu 4. MODE and press ENTER
button. The currently set operation mode is displayed on the screen. The setting is changed with
pressing up/down arrow buttons:
- SOUND+STROBE – set by default. Both the strobe light and sound are active in case
of fire alarm event.
- SOUND. Only the sound is active in case of fire alarm event.
- STROBE. Only the strobe is active in case of fire alarm event.
- DISABLED.
Confirm the setting with ENTER button – the exit of the menu is automatic.
