Simpo Addressable Panel
Programming and configuration:
• The panel can be programmed and configured using the buttons on the front
panel.
• The panel can be programmed via software ProsTE of Teletek-Electronics with
direct PCB serial connection.
• Possibility of remote programming and controlling with AJAX LAN/GPRS modules,
connected directly on the main PCB – Serial.
Monitoring:
• The panel has build in Bacnet and/or Modbus Server for online monitoring – with
use of AJAX LAN/GPRS modules.
• The panel can be monitored in local network via RS 485 port.
• Possibility of integration with ALVIS software for monitoring or Teletek-Electronics
Observer monitoring software.
Network:
• The system supports redundant network for up to 32 panels.
• The connection is via BUS - RS 485 port located on the mainboard.
• Each panel can be Repeater of the others in the network (Selectable from the
system menu).
Repeater:
• Each regular panel Simpo can be set as repeater from it’s system menu.
• There will be a special Low-price and more compatible Just repeater panel with
only repeating functionality. It will be in smaller box and will have just LCD screen, LED
indication and buttons for RESET, EVACUATION, SILENCE ALARM and SILENCE BUZZER.
Also the buttons for the extinguish module.
System events LOG:
• Supports up to 10 000.
• In case of reaching the maximum number of events (10 000), the newest event
replaces the last one from the LOG.
• The LOG file consist information about the date and time of the event, address
and name of the device, number and name of the zone.
Main Power Supply:
• Model: MeanWell PS-65-13,5
• Single Output Switching Power Supply
• Input: 90 ~ 264 VAC, 47 ~ 440 Hz
• Output: 13,5 VDC, 4.7 A, 63.5 W
• Designed according to EN-54/4
Backup Power Supply:
• Single Output Lead-Acid Sealed battery 12 V DC, 18 Ah
