3 – Description of the LCD-module
The SIMPO fire alarm addressable panel is equipped with letter-digit LCD-module (4 rows x 40 symbols). The user can
enter device and zone names using the navigation and control buttons. The display has an adjustable backlight with 20
levels of intensity.
4 – Description of the functional digit buttons:
1 - 4
Access level 1:
- Review the current messages for events.
Access level 2 (Maintenance):
- Entering an access code.
- Functional submenu entry.
- Changing of value or parameter status.
5 – Description of control and navigation buttons:
Silence Buzzer The button functionality is deactivation of the internal buzzer.
The button functionality is deactivation of the sounders in case of fire alarm event.
After pressing the button, the LED next to it is lighting in yellow.
Reset
The button functionality is resetting the panel without switching off the main power
supply.
Evacuation
The button immediately activates the sounders – the sounder delay is ignored if
present.
Buzzer and LED
general test
The button will activate all LEDs on the front panel – for events and zones, as and
the internal buzzer. The next pressing of the button deactivates the test.
ENTER
(Confirmation)
Use the button to confirm the entered values and parameters; in the devices and
zones menus use the button to enter in a submenu for name and status changing.
CANCEL
(Rejection)
Use the button to reject the entered values and parameters; one step back to the
previous menu.
Navigation
buttons
Use the arrows to scroll over the menus; in maintenance menus the buttons has a
specific function for changing values and switching between the editable fields.
The navigation buttons have the following functionalities in operation:
Menu entry; Confirmation of entered parameters and settings.
Cancelation of entered parameters and settings; Step back in the menu structure.
Scrolling between menus; Increasing values; Text entering.
Scrolling between menus; Decreasing values; Text entering.
Changing the editing fields.
