DUAL A/D CHANNEL PROCESSOR
18
6. - Device control
This version of the DUAL A/D CHANNEL PROCESSOR
allows conguration and monitoring via a PC, both
locally and remotely.
a. Local control
The “Headend Management” programme
(v2.1.4.59 or higher) is required, as well as a special
lead (provided with the programme) that connects
a PC serial port to the “PRGM” socket of the DUAL
A/D CHANNEL PROCESSOR.
The programme can be used to set up and read all
the operating parameters, as well as to monitor the
correct operation of the device.
b. Remote control
It is necessary to have a Headend Control module
(ref. 555902) that includes the programme
mentioned above.
Once the communication with the headend
control has been established, all the controllable
devices that have been installed in the headend
can be accessed. In this case it is imperative that
each module is programmed with a dierent
device address selected between 1 and 254.
Menu
ow chart
M A I N M E N U
E X T E N D E D M E N U
Long press
“
”
At any moment,
modules A and B
can be switched by
pressing keys and
when the cursor is
over the A/B indication
situated on the upper
left corner.
To Next Page
