Televes 564980 User Manual

EN
5
Down-Converter
Input frequency (selec.) MHz 46 - 862 IN/OUT Connectors type female “F”
Input level dBmV -10 to 20* Input impedance ohm 75
Frequency steps
(selec.)
Analog
KHz
250 Input line powering for preamps (< 50 mA) Vdc 12 / 24 / OFF
Digital 166.66 / 125 / 25 Input loop-through gain dB 0 ± 3
Intermediate freq. Bandwidth MHz 6
UP-Converter
Output frequency (selec.) MHz 46 - 862 Output loop-through losses (typ.) dB < 1.5
Frequency steps
(selec.)
Analog
KHz
250 Return losses (typ.) dB > 12
Digital 166.66 / 125 / 25 IN/OUT Connectors type female “F”
Phase noise (typ.) dBc/Hz 80 @10KHz Output impedance ohm 75
Output level dBmV 20 ±5 Spurious level (min.) dBc 55
Output level regulation dB > 15
General
Consumption (typ.) mA
400 @ 24V
(
LNB power OFF)
450 @ 24V
(LNB power ON)
Protection level IP 20
* Automatic gain for high level input signals.
These technical specications are dened for a maximum ambient temperature of 113 °F (45 ° C). For higher temperatures forced ventilation is required.
1. Technical specifications
1.1. DUAL A/D CHANNEL PROCESSOR ref. 564980
