saved using Learning Plan.
- Audio Carrier: 4.5 MHz, 5.5 MHz, 6.0 MHz,
6.5 MHz.
- Test port Compensation: O / 1 dB to 30 dB.
Automatic compensation of the measures for
ports with attenuation.
- Bluetooth (Option 593213 or Reference
593180): Allows to turn ON/OFF the
bluetooth connection.
If ON is selected, it will appear a new line
showing the MAC of the H30 Bluetooth
interface, and a bluettoth icon will be shown
in the top right part of the screen.
When the equipment connects via bluetooth
with another device, it will appear another
line showing the MAC of the other device.
- Network:
Setup: Manual, Auto
IP.
When Setup Manual is selected, the user
must set the IP.
Gateway.
When Setup Manual is selected, the user
must set the gateway.
DNS.
When Setup Manual is selected, the user
must set the DNS.
- Time and Date:
Set current time (hour and minutes) and
date (day of the month, month and year).
- Remote datalogs: Allows to download all
the datalogs saved in the H30 to a remote
server specied by the user
Sync: ON/OFF
If ON is selected, the datalogs will be
downloaded automatically when the H30
detects that is connected to internet, either
trough Ethernet or via DOCSIS (only
for 593103 and 593104)
FTP Server:
Enter the server’s name using
Path:
Enter the path where you want to save
the datalogs in the server.
A new folder with the name of your
H30 serial number will be created
automatically in the Path indicated
bellow.
User:
Enter the user name to access the
server using
Password:
Enter the corresponding password
using
- Energy:
Auto suspension
Auto shutdown
- Update rmware: ON, OFF
When ON, every time the H30 is connected
to the internet, it will allow the user to
update the rmware if a new version is
available.
- Licenses: Shows the options included in you
H30
- About SW: Shows the rmware version
- About HW: Shows the serial number, the
ethernet MAC, and the modem MAC (only
for 593103 and 593104)
