H30 - CATV & DOCSIS3.0 Meter / Analyzer
6
General Specification
Display 2.8”TFT 400 x 240 full colour
Weight
Ref. 593101 & 593102: 12.12lb (510g)
Ref. 593103 & 593104: 1.39lb (632.2g)
Dimensions 6.9 x 3.9 x 2 in /175 x 100 x 52 mm(H x W x D)
AC Adaptor
Input: 100-240V~ 50-60Hz
Output: 12VDC, 2A
Battery LiIon smart battery (7.2VDC, 2300mAh)
Operating Time Up to 4 hours
Operating Temperature 23ºF to 104ºF (-5ºC to 45ºC)
Storage Temperature -4ºF to 158ºF (-20ºC to 70ºC)
Humidity 5% to 95% non-condensing
Ruggedness Survives 1 m (3 ft) drop to concrete on all sides
Communication
Interfaces
RJ45 10/100-T Ethernet interface for Remote Control, Measurements,
Datalog Retrieval andAutomatic Software Updates
Storage 400 MB (internal) for measurements
Power up time < 10 seconds
