4. Electrical Specifications
4.1. Absolute Maximum Ratings – Not Operational
A deviation from the value ranges listed below may harm the LE910C1 module.
Table 7: Absolute Maximum Ratings – Not Operational
Symbol Parameter Min Max Unit
VBATT Battery supply voltage on pin
VBATT
-0.5 +6.0 [V]
VBATT TRANSIENT Transient voltage on pin
VBATT (< 10 ms)
-0.5 +7.0 [V]
VBATT_PA Battery supply voltage on pin
VBATT_PA
-0.3 +6.0 [V]
4.2. Recommended Operating Conditions
Table 8: Recommended Operating Conditions
Symbol Parameter Min Typ Max Unit
T
amb
Ambient temperature -40 +25 +85 [°C]
VBATT Battery supply voltage
on pin VBATT
3.4 3.8 4.2 [V]
VBATT_PA Battery supply voltage
on pin VBATT_PA
3.4 3.8 4.2 [V]
I
BATT_PA +
I
BATT
Peak current to be used
to dimension
decoupling capacitors
on pin VBATT_PA
- 80 2000 [mA]
