Pad Parameter Min Max Unit Comment
V
OL
Output low level 0V 0.4V [V]
I
IL
Low-level input leakage current -2 - [uA] No pull-up
I
IH
High-level input leakage current - 2 [uA] No pull-down
R
PU
Pull-up resistance 10 100 [kΩ]
R
PD
Pull-down resistance 10 100 [kΩ]
C
i
Input capacitance 5 [pF]
4.3.5. Dual Voltage Pads - Absolute Maximum Ratings
Table 13: Absolute Maximum Ratings - Not Functional
Parameter Min Max
Input level on any
digital pin when on
-0.3V +3.6V
Input voltage on
analog pins when on
-0.3V +3.6 V
4.3.6. SD Card Pads @ 2.95V
Table 14: Operating Range – For SD Card Pads Operating at 2.95V
Pad Parameter Min Max Unit Comments
V
IH
Input high level 1.9V 3.1V [V]
V
IL
Input low level -0.3V 0.7V [V]
V
OH
Output high level 2.1V 3.05V [V]
V
OL
Output low level 0V 0.4V [V]
I
IL
Low-level input leakage current -10 [uA] No pull-up
I
IH
High-level input leakage current 10 [uA] No pull-down
R
PU
Pull-up resistance 10 100 [kΩ]
