ME910C1 HW User Guide
1VV0301351 Rev.8 Page 17 of 99 2018-09-28
P2 VBATT_PA -
Main power supply (Radio
PA)
Power
E1 GND - Ground Power
G1 GND - Ground Power
H1 GND - Ground Power
J1 GND - Ground Power
L1 GND - Ground Power
A2 GND - Ground Power
E2 GND - Ground Power
F2 GND - Ground Power
G2 GND - Ground Power
H2 GND - Ground Power
J2 GND - Ground Power
K2 GND - Ground Power
L2 GND - Ground Power
R2 GND - Ground Power
M3 GND - Ground Power
N3 GND - Ground Power
P3 GND - Ground Power
R3 GND - Ground Power
D4 GND - Ground Power
