ME910C1 HW User Guide
1VV0301351 Rev.8 Page 79 of 99 2018-09-28
Be aware of max bias current in case of unwanted short on antenna cable, decoupling
inductor may be demaged.
In case of LNA with 1.8V supply, VAUX/POWERMON pin can be used to supply active
GNSS antenna
GNSS Characteristics *
The table below specifies the GNSS characteristics and expected performance
The values are related to typical environment and conditions Table 1 GNSS Characteristics
(* external LNA)
Parameters
Typical
Measurement
Notes
Sensitivity
Standalone or MS Based
Tracking Sensitivity
-161 dBm
Navigation -158 dBm
Cold Start Sensitivity -146 dBm
TTFF
Hot <1s GNSS Simulator test
Warm 21s GNSS Simulator test
Cold 32s GNSS Simulator test
Min Navigation update rate 1Hz
Dynamics 2g
A-GPS Supported
