Telit Wireless Solutions ME910C1-WW - Digital Section; Power On

ME910C1 HW User Guide
1VV0301351 Rev.8 Page 36 of 99 2018-09-28
5. DIGITAL SECTION
Logic Levels
Power On
To turn on the ME910C1 the pad ON_OFF*/WAKE* must be tied low for at least 5 second
and then released.
The maximum current that can be drained from the ON_OFF*/WAKE* pad is 0,1 mA.
ON_OFF*/WAKE* pad can make an asynchronous wakeup of the system from the PSM
Mode, before the scheduled event of timer T3412 expired.
To make asynchronous exit from PSM mode ON_OFF*/WAKE* pin must be set LOW for at
least 5 seconds.
Parameter Min Max
ABSOLUTE MAXIMUM RATINGS – NOT FUNCTIONAL
Input level on any digital pin (CMOS 1.8) with respect to ground -0.3V 2.1V
Operating Range - Interface levels (1.8V CMOS)
Input high level 1.5V 1.9V
Input low level 0V 0.35V
Output high level 1.6V 1.9V
Output low level 0V 0.2V
Parameter
AVG
CURRENT CHARACTERISTICS:
Output Current 1mA
Input Current 1uA
