ME910C1 HW User Guide
1VV0301351 Rev.8 Page 26 of 99 2018-09-28
Power Consumption
*Preliminary data
Mode Average
(mA)
Mode Description
Switched off 0.008mA Module supplied but switched off
IDLE mode
AT+CFUN=1 12 mA Normal mode: full functionality of the module
AT+CFUN=4 11 mA Disabled TX and RX; module is not registered on
the network
AT+CFUN=5 2.3 mA Paging cycle #64 frames (0.64 sec DRx cycle)
1.4 mA Paging cycle #128 frames (1.28 sec DRx cycle)
1.1 mA Paging cycle #256 frames (2.56 sec DRx cycle)
Operative Mode
(LTE) CAT M1
Data call
10MHz RB=1
190mA VBATT_PA+VBATT TX=23dBm
112mA VBATT_PA+VBATT TX=0dBm
(LTE) CAT NB1
Data call
50mA VBATT_PA+VBATT TX=23dBm
30mA VBATT_PA+VBATT TX=0dBm
GPRS Data call
1TX+1RX slots,
GSM900
240mA VBATT_PA+VBATT TX=33dBm
112mA VBATT_PA+VBATT TX=0dBm
GPRS Data call
4TX+1RX slots,
GSM900
520mA VBATT_PA+VBATT TX=28dBm
130mA VBATT_PA+VBATT TX=0dBm
