ME910C1 HW User Guide
1VV0301351 Rev.8 Page 59 of 99 2018-09-28
The following table is showing the ADC characteristics:
Item Min Typical Max Unit
Input Voltage range 0 - 1.8 Volt
AD conversion - - 10 bits
Input Resistance 1 - - Mohm
Input Capacitance - 1 - pF
The ADC could be controlled using an AT command.
The command is AT#ADC=1,2
The read value is expressed in mV
Refer to SW User Guide or AT Commands Reference Guide for the full description of this
function.
