Power Consumption
Preliminary data
*Based on chipset reference data
Mode
Measure
Mode Description
IDLE MODE
CATM
Typical
(mA)
NBIoT
Typical
(mA)
AT+CFUN=1
9.5
9.2
Normal mode: full functionality of the module
AT+CFUN=4
9.0
Disabled TX and RX; module is not
registered on the network
AT+CFUN=5
0.98*
0.87*
Paging cycle #256 frames (2.56s DRx cycle)
0.44*
0.47*
81.92s eDRx cycle length (PTW=2.56s,
DRX=1.28s)
0.23**
-***
327.68s eDRx cycle length (PTW=2.56s,
DRX=1.28s)
0.12**
-***
655.36s eDRx cycle length (PTW=2.56s,
DRX=1.28s)
0.06**
-***
1310.72s eDRx cycle length (PTW=2.56s,
DRX=1.28s)
0.03**
-***
2621.44s eDRx cycle length (PTW=2.56s,
DRX=1.28s)
PSM MODE
Typical (mA)
AT+CPSMS=1
3uA
No current source or sink by any connected
pin
OPERATIVE MODE
LTE CAT M1
Data Call
105
TX=0dBm, BW=10MHz, Max Throughput
375Kbps (DL)
LTE CAT NB1
Data Call
49
TX=0dBm
