On gearbox side by going under the stator,
screw by hand completely 3 new screws in
order to secure the hub.
View of the 3 screws under stator (gearbox
side).
Check that all output coils (black and red)
of the 8 coils, are in front of the notch
locations.
Check that all the spring washers are well
located on the top of the coils.
