Teltonika RUT230 Quick Start Guide

1. To enter the router's Web interface (WebUI), type http://192.168.1.1 into the URL field of your Internet browser.
2. Use login information shown in image A when prompted for authentication.
3. After you login, you will be prompted to change your password for security reasons. The new password must
contain at least 8 characters, including at least one uppercase letter, one lowercase letter and one digit. This step is
mandatory and you will not be able to interact with the router's WebUI before you change the password.
4. When you change the router's password, the Configuration Wizard will start. The Configuration Wizard is a tool
used to setup some of the router's main operating parameters.
5. Go to Overview page and pay attention to the Signal Strength indication (image B). To maximize the cellular
performance try adjusting the antennas or changing the location of your device to achieve the best signal
conditions.
LOGIN TO DEVICE
TECHNICAL INFORMATION
*Order code dependent.
**Higher gain antenna can be connected to compensate for cable attenuation when a cable is used. The user is responsible for the compliance with the legal regulations.
Radio specifications
Bundled accessories specifications*
RF technologies
Max RF power
2G, 3G, WiFi
33 dBm@GSM, 24 dBm@WCDMA, 20 dBm@ WiFi
Mobile antenna 698~960/1710~2690 MHz, 50 Ω, VSWR<3, gain** 3 dBi, omnidirectional, SMA male connector
Power adapter Input: 0.4A@100-240VAC, Output: 9VDC, 1A, 4-pin plug
WiFi antenna 2400~2483.5 MHz, 50 Ω, VSWR<2, gain** 5 dBi, omnidirectional, RP-SMA male connector
-65 dBm
Data connection state
SIM card slot in use
Bytes received/sent *
State
Registered (home); OPERATOR; 3G
Connected
348.7 KB / 223.5 KB
Ready

Teltonika RUT230 Specifications

General

Ethernet WAN	Yes
3G/4G USB modem compatibility	No
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	150 Mbit/s
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Ethernet LAN (RJ-45) ports	2
2G standards	EDGE, GPRS, GSM
3G standards	HSDPA, HSPA+, HSUPA, UMTS
Data network	2G, 3G, EDGE, GPRS, GSM, HSDPA, HSPA+, HSUPA, UMTS
GSM bands supported	850, 900, 1800, 1900 MHz
EDGE multislot class	12
UMTS bands supported	900, 2100 MHz
Number of simultaneous SIM cards	1
Output voltage	9 V
AC input voltage	100 - 240 V
Power source type	AC
Antenna connector type	RP-SMA
Device type	Cellular network router
Product type	Tabletop router
Product color	Black
LED indicators	WLAN
Processor frequency	400 MHz
Storage temperature (T-T)	-45 - 80 °C
Operating temperature (T-T)	-40 - 75 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2

Weight and Dimensions

Depth	74 mm
Width	83 mm
Height	25 mm
Weight	125 g
Dimensions (WxDxH)	83 x 74 x 25 mm
