Teltonika RUT950 Manual

5
IoT PLATFORMS
SYSTEM CHARACTERISTICS
FIRMWARE / CONFIGURATION
FIRMWARE CUSTOMIZATION
POWER
PHYSICAL INTERFACES (PORTS, LEDS, ANTENNAS, BUTTONS, SIM)
Can send device IP, Number of bytes send/received/ 3G connection state, Network link state, IMEI, ICCID, Model, Manufacturer,
Serial, Revision, IMSI, Sim State, PIN state, GSM signal, WCDMA RSCP WCDMA EC/IO, LTE RSRP, LTE SINR, LTE RSRQ, CELL ID,
Operator, Operator number, Connection type, Temperature, PIN count to Azure IoT Hub server
Azure IoT Hub
Allows monitoring of: Device Model, Revision and Serial Number, Mobile Cell ID, ICCID, IMEI, Connection Type, Operator, Signal
Strength, WAN Type and IP
Cumulocity
Allows monitoring of: Device data, Mobile data, Network info, Availability
Allows monitoring of: WAN Type, WAN IP Mobile Operator Name, Mobile Signal Strength, Mobile Network Type
Clouds of things
ThingWorx
Atheros Wasp, MIPS 74Kc, 550 MHz
CPU
128 MB, DDR2
16 MB, SPI Flash
RAM
FLASH storage
Update FW from file, check FW on server, configuration profiles, configuration backup, restore point
WEB UI
Update FW/configuration from server
Update FW/configuration for multiple devices
FOTA
RMS
Update FW without losing current configuration
Keep settings
RutOS (OpenWrt based Linux OS)
Operating system
Busybox shell, Lua, C, C++
SDK package with build environment provided
Supported languages
Development tools
4 pin industrial DC power socket
Connector
9 – 30 VDC, reverse polarity protection; surge protection >31VDC 10us max
Passive PoE over spare pairs. Possibility to power up through LAN port, not compatible with IEEE802.3af, 802.3at and 802.3bt
standards
Input voltage range
PoE (passive)
< 2 W idle, < 7 W Max
Power consumption
4 x RJ45 ports, 10/100 Mbps
Ethernet
1 x Digital Input, 1 x Digital Output on 4 pin power connector (available from HW revision 1600)
1 x bi-color connection status LED, 5 x connection strength LEDs, 4 x LAN status LEDs, 1 x Power LED
I/O’s
Status LEDs
2 x SIM slots (Mini SIM - 2FF), 1.8 V/3 V, external SIM holders, eSIM (Optional)
SIM
1 x 4 pin power connector
Power
2 x SMA for LTE, 2 x RP-SMA for WiFi antenna connectors
Antennas
Reboot/User default reset/Factory reset button
Reset
DATASHEET // RUT950
INPUT/OUTPUT
1 x Digital input, 0 - 6 V detected as logic low, 8 - 30 V detected as logic high
Input
1 x Digital open collector output, max output 30 V, 300 mA
SMS, EMAIL, RMS
Output
Events
Copyright © 2021, TELTONIKA NETWORKS. Specifications and information given in this document are subject to change by TELTONIKA NETWORKS without prior notice.

Teltonika RUT950 Specifications

General

Wi-Fi band	-
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Mobile network connection	Yes
Mobile network generation	3G
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
USB port	No
Ethernet LAN (RJ-45) ports	4
4G standard	LTE
2G standards	GSM
3G standards	HSPA+, UMTS
GSM bands supported	850, 900, 1800, 1900 MHz
UMTS bands supported	850, 900, 1900, 2100 MHz
Device type	Cellular network router
Product type	Tabletop router
Product color	Black
LED indicators	LAN, Power
Housing material	Aluminum
Processor frequency	560 MHz
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2
Output voltage	9 V
AC input voltage	100 - 240 V
Power source type	AC
Power consumption (typical)	7 W
Storage temperature (T-T)	-45 - 80 °C
Operating temperature (T-T)	-40 - 75 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	80 mm
Width	106 mm
Height	46 mm
Weight	250 g
