Telwin BATTERY MANAGER - B TEST; Charge Status Test; Battery Start Capability Test

- 57 -
B TEST
CHARGE STATUS

TEST SELECTION
DISPLAY

BATTERY TYPE SELECTION
DISPLAY

CLAMP CONNECTION
Info
Alarm

VOLTAGE SELECTION
DISPLAY
Info
Alarm

END OF TEST - EXAMPLE
DISPLAY LEGENDA
to be charged to be charged full
B TEST
BATTERY START
CAPABILITY

TEST SELECTION
DISPLAY

CLAMP CONNECTION
Info
Alarm

VOLTAGE SELECTION
DISPLAY
Info
Alarm
DISPLAY

VEHICLE’S STARTING

END OF TEST - EXAMPLE
DISPLAY LEGENDA
working
sufficient insufficient
