Telwin BATTERY MANAGER - D POWER SUPPLY; Supply

- 61 -
D POWERSUPPLY
SUPPLY

ADVANCED MENU SELECTION
3"
BEEEP
MENU
ADVANCED
PROGRAMS

FUNCTION SELECTION
DISPLAY
VOLTAGEBETWEENCLAMPS
(6 ÷ 27V).

VOLTAGE SELECTION
DISPLAY
Info
Alarm
3A
VOLTAGE CUSTOMIZATION -
EXAMPLE
CHECK MAX. VOLTAGE ALLOWED
IN THE VEHICLE MANUFACTURER’S
INSTRUCTIONS.
3"
BEEEP
DISPLAY
13.3V
13.2V
13.1V
. . . . .
. . . . .
13.7V
13.6V
13.5V
3B
CURRENT ADJUSTMENT -
EXAMPLE
3A 7A 10A 20A 30A 40A
►
3A 7A 10A 20A 30A 40A

DISPLAY - EXAMPLE

CLAMPS CONNECTION TO
VEHICLE’S BATTERY CABLES

SUPPLIED VEHICLE
 
BATTERY BATTERY
REMOVAL CHANGE

EXIT - ADVANCED MENU
3"
BEEEP
KEYBOARD LOCK / UNLOCK
LOCK
3"
DISPLAY
UNLOCK
3"
DISPLAY
BATTERY
CHANGE
