DIGITAL PID CONTROLLER
3. Dimensions and P
anel cutouts
11
1) T52 (48x96 mm) Dimensions
2) T53 (96x48 mm) Dimensions
3) T54 (48x48 mm) Dimensions
10.0
77.0
96.0
91.0
48.0
96.0
96.0
48.0
48.0
43.6
10.0
77.0
8.8
48.0
44.9
48.0
77.0
48.0
T52 / T53 (96x48)
Panel cutouts
(Unit: mm)
45
±0.5
92
±0.5
Min. 30
Min. 20
T54 (48x48)
Panel cutouts
(Unit: mm)
Min.17
Min.17
45
+0.5
-0
45
+0.5
-0
11
13
