Temposonics E Series - Technical Data of Temposonics EP

Temposonics
®
E-Series IO-Link
Operation Manual
I 35 I
6/ Selectable via IO-Link master
7/ Magnet slider # 252 182 and # 252 184, U-magnet # 251 416-2, block magnet # 403 448
8/ The IP rating IP67 is only valid for the sensor electronics housing, as water and dust can get inside the profile.
9.2 Technical data of Temposonics
®
EP
Output
Interface Digital
Transmission protocol IO-Link V1.1
Data format 32 bit signed (position in m)
Data transmission rate COM3 (230.4 kBaud)
Process data device – master 4 bytes
Process data master – device 0 bytes
Error value 0
Measured value Position
Measurement parameters
Resolution
6
5 µm, 10 µm, 20 µm, 50 µm or 100 µm
Cycle time Sensors with stroke length ≤ 1000 mm (≤ 39 in.): 1 ms / Sensors with stroke length > 1000 mm (> 39 in.): 2 ms
Linearity
7
Magnet slider: ≤ ±0.02 % F.S. (minimum ±60 m), U-magnet: ≤ ±0.02 % F.S. (minimum ±60 m),
block magnet: ≤ ±0.03 % (minimum ±90 µm)
Repeatability ≤ ±0.005 % F.S. (minimum ±20 m)
Operating conditions
Operating temperature −40…+75 °C (−40…+167 °F)
Humidity 90 % rel. humidity, no condensation
Ingress protection
8
IP67 (correctly fitted)
Shock test 100 g (single shock), IEC standard 60068-2-27
Vibration test 15 g / 10…2000 Hz, IEC standard 60068-2-6 (resonance frequencies excluded)
EMC test Electromagnetic emission according to EN 61000-6-3
Electromagnetic immunity according to EN 61000-6-2
The sensor meets the requirements of the EC directives and is marked with
.
Magnet movement velocity Magnet slider: ≤ 5 m/s; U-magnet: Any; block magnet: Any
Design / Material
Sensor electronics housing Aluminum
Sensor profile Aluminum
Stroke length 50…2540 mm (2…100 in.)
Mechanical mounting
Mounting position Any
Mounting instruction Please consult the technical drawings on page 14
Electrical connection
Connection type M12 male connector (4 pin)
Operating voltage +24 VDC (±25 %)
Ripple ≤ 0.28 V
pp
Current consumption < 50 mA
Dielectric strength 500 VDC (DC ground to machine ground)
Polarity protection Up to −30 VDC
Overvoltage protection Up to 36 VDC
