Temposonics E Series - Order Code of Temposonics el

Temposonics
®
E-Series IO-Link
Operation Manual
I 7 I
*/ Non standard stroke lengths are available; must be encoded in 5 mm / 0.1 in. increments
3.3 Order code of Temposonics
®
EL
1 2 3 4 5 6 7 8 9 10 11 12 13
E
L 0
D 4 4
1
K
ab c d ef
b Design
0
Without position magnet
a Sensor model
E L
Ultra low profile
d Connection type
D 4 4
M12 (4 pin) male connector
e Operating voltage
1
+24 VDC (±25 %)
f Output
K
IO-Link
c Stroke length
X X X X M
0050…2540 mm
Standard stroke length (mm*) Ordering steps
50 … 500 mm 25 mm
500…2540 mm 50 mm
X X X X
U
002.0…100.0 in.
Standard stroke length (in.) Ordering steps
2 … 20 in. 1.0 in.
20 …100 in. 2.0 in.
.
