Temposonics E Series - Identification; Order Code of Temposonics EH

Temposonics
®
E-Series IO-Link
Operation Manual
I 5 I
3.1 Order code of Temposonics
®
EH
*/ Non standard stroke lengths are available; must be encoded in 5 mm / 0.1 in. increments
3. Identification
1 2 3 4 5 6 7 8 9 10 11 12 13
E H
D 4 4
1
K
ab c d ef
b Design
EH rod-style sensor with housing material 1.4305 (AISI 303)
and rod material 1.4301 (AISI 304)
K
Flange M18×1.5-6g, 7 mm rod Ø
L
Flange ¾" - 16 UNF -3A, 7 mm rod Ø
EH rod-style sensor with housing material 1.4305 (AISI 303)
and rod material 1.4306 (AISI 304L)
M
Flange M18×1.5-6g, 10 mm rod Ø
S
Flange ¾"- 16 UNF -3A, 10 mm rod Ø
EH rod-style sensor with housing material 1.4404 (AISI 316L)
and rod material 1.4404 (AISI 316L)
F
Flange ¾"-16 UNF -3A, 10 mm rod Ø
W
Flange M18×1.5-6g, 10 mm rod Ø
a Sensor model
E H
Rod
d Connection type
D 4 4
M12 (4 pin) male connector
e Operating voltage
1
+24 VDC (±25 %)
f Output
K
IO-Link
c Stroke length
X X X X M
0050…2540 mm
X X X X
U
002.0…100.0 in.
.
Standard stroke length (mm*) Ordering steps
50 … 500 mm 5 mm
500 … 750 mm 10 mm
750…1000 mm 25 mm
1000…2540 mm 50 mm
Standard stroke length (in.) Ordering steps
2 … 20 in. 0.2 in.
20 … 30 in. 0.5 in.
30 … 40 in. 1.0 in.
40…100 in. 2.0 in.
