INSTALLATION INSTRUCTIONS Gas Furnace: (F/G)MAC
24 440 01 4201 01
Specifications subject to change without notice.
External Filter Cabinet Configurations
Figure 29 Accessory Side Filter Rack
TABS
FILTER
FRAME
FILTER
DOOR
FURNACE
L10F027
OPENING
TABS
(TYP.)
3
4”
/
OPENING
14
1
2”
/
16
1
8”
/
2
3
8”
/
1
2”
/
3
8”
/
1
1
4”
/
1
1
4”
/
25
1
8”
/
17
1
8”
/
23
1
8”
/
Figure 30 Accessory Bottom Filter Rack
L10F031
B
A
28−7/16
(722.2)
22−5/16
(566.4)
2−3/16
(55.5)
A
Table 7 Dimensional Drawing − inch (mm)
KIT NO.
FURNACE
WIDTH
A B
NAHB00601FF
17−1/2
(444.5)
14−5/8
(371.5)
17−5/8
(447.7)
NAHB00701FF
21
(533.4)
18−1/8
(460.4)
21−1/8
(536.6)
NAHB00801FF
24−1/2
(622.3)
21−5/8
(549.3)
24−5/8
(625.5)
