CF Series Portable Chiller : Air & Water-Cooled : 5 - 40 Tons
Page: 12
TEMPTEK, INC.
525 East Stop 18 Road Greenwood, Indiana 46142
317-887-6352 Fax: 317-881-1277
Email: service@Temptek.com
Air-Cooled Model 10 ton unit shown.
ABS fascia and enclosure panels
removed for photo.
Water-Cooled Model 10 ton unit shown.
ABS fascia, top and enclosure panels
removed for photo.
Caster
Compressor
Liquid Line Solenoid
Filter Drier
Refrigerant Site Glass
Fan Motor
Protective Fan Shroud
Bypass
Bypass
Water Regulator
Valve
Coolant Pump
Water-Cooled
Condenser
Electrical Cabinet
Pressure Gauges
Compressor
Insulated
Reservoir
Air Discharge
Coolant Pump
Pressure Gauges
Expansion Valve
Insulated Reservoir Tank
Electrical Cabinet
Refrigerant Low Pressure Limit
Refrigerant High Pressure Limit
Air-Cooled Condenser
