CF Series Portable Chiller : Air & Water-Cooled : 5 - 40 Tons

Page: 59

TEMPTEK, INC.

525 East Stop 18 Road Greenwood, Indiana 46142

317-887-6352 Fax: 317-881-1277

Email: service@Temptek.com

7.0 RELATED DRAWINGS

7.1 Mechanical Schematic : Water-Cooled : 5 - 10 tons

7.2 Mechanical Schematic : Water-Cooled : 15 - 40 tons

7.3 Mechanical Schematic : Air-Cooled : 5 - 10 tons with Propeller Fans

7.4 Mechanical Schematic : Air-Cooled : 15 - 30 tons and 5 - 20 ton Models with

Optional Centrifugal Blower

7.5 Typical Electrical : Air-Cooled

7.6 Typical Electrical : Water-Cooled

7.7 Typical Physical : Air-Cooled models : 5 tons

7.8 Typical Physical : Air-cooled models : 7.5 - 10 tons

7.9 Typical Physical : Air-cooled models : 15 - 20 tons Fan Cooled

7.10 Typical Physical : Air-cooled models : 15 - 30 tons with Blower

7.11 Typical Physical : Air-cooled models : 5 - 10 Tons with Remote Condenser

7.12 Typical Physical : Air-cooled models : 15 - 30 Tons with Remote Condenser

7.13 Typical Physical : Water-Cooled models : 5 tons

7.14 Typical Physical : Water-Cooled models : 7.5 - 10 tons

7.15 Typical Physical : Water-Cooled models : 10 - 30 tons

7.16 Typical Physical : Water-Cooled models : 40 tons

7.17 Duct Schematic for Air-cooled Chillers
