3.1 GENERAL
A. Failuretofollowthefactoryrequiredoperationsproceduremayadverselyaffecttheunit’s
ability to adequately control process temperature and may create a hazardous operating
condition which may result in serious operator injury and/or unit damage.
B. The OPERATIONS segment of this manual is divided into the following sections:
3.2 Start up/operations - follow this segment to start the unit after the initial
installation to the process system or to restart the unit after reinstallation to the
same or different process system. This section includes information on system
ll,electricmotorphasing(motorrotation)andprocessowadjustments.
3.3 Chiller Control - follow this segment to start up and operate the chiller control.
This section includes information on setpoint selection and adjustment, and
feature explanations.
3.4 Shut down procedure - follow this segment to shut down the unit. This segment
includes information on system shut down, electrical power supply precautions,
and disconnection from system.
3.2 START UP / OPERATION PROCEDURE
A. System Fill
1. Foroperatingtemperaturesfrom48°Fto80°Fusewatertolltheunit.
For operating temperatures below 48°F a water and propylene glycol mixture
must be used. An inhibited propylene glycol can be used for operating
temperatures above 48°F if desired to prevent corrosion and scaling. Use the
minimum ratio that is recommended by the glycol manufacturer. See section 8 of
this manual for more information.
2. Theunithasaninternalreservoirwhichmustbelledandmaintainedforproper
operation. The unit has a level switch mounted at the proper water level in the
reservoir. Some units are customized to draw water from an owner supplied
external reservoir and will not have an internal reservoir. These units will normally
have an “R” in the model number. Example: M1D-10AR and are referred to as
“reverseow”.SeeSection6.3.Jformoreinformation.
Please note, Sections 3.2.A & 5.4 are not applicable for reverse ow units.
WARNING: Follow all Factory operations procedures. Failure to do so may create a hazardous
operating condition which may result in serious operator injury and/or unit damage.
NOTICE: See Section 8 of this Manual if using a water & glycol uid mixture.
