Temptek CF Series - Page 5

CF Series Portable Chiller : Air & Water-Cooled : 5 - 40 Tons
Page: 5
TEMPTEK, INC.
525 East Stop 18 Road Greenwood, Indiana 46142
317-887-6352 Fax: 317-881-1277
Email: service@Temptek.com
7.0 RELATED DRAWINGS 59
7.1 Mechanical Schematic : Water-Cooled : 5 - 10 Tons 60
7.2 Mechanical Schematic : Water-Cooled : 15 - 40 Tons 61
7.3 Mechanical Schematic : Air-Cooled : 5 - 10 Tons 62
7.4 Mechanical Schematic : Air-Cooled : 15 - 30 Tons 63
7.5 Typical Electrical : Air-Cooled 64
7.6 Typical Electrical : Water-Cooled 65
7.7 Typical Physical : Air-Cooled : 5 Tons 66
7.8 Typical Physical : Air-Cooled : 7.5 - 10 Tons 67
7.9 Typical Physical : Air-Cooled : 15 - 20 Tons Fan Cooled 68
7.10 Typical Physical : Air-Cooled : 15 - 30 Tons Blower 69
7.11 Typical Physical : Air-Cooled : 5 - 10 Tons With Remote Condenser 70
7.12 Typical Physical : Air-Cooled : 15 - 30 Tons With Remote Condenser 71
7.13 Typical Physical : Water-Cooled : 5 Tons 72
7.14 Typical Physical : Water-Cooled : 7.5 - 10 Tons 73
7.15 Typical Physical : Water-Cooled : 15 - 30 Tons 74
7.16 Typical Physical : Water-Cooled : 40 Tons 75
7.17 Duct Schematic for Air-Cooled Chillers 76
8.0 APPENDIX 77
8.1 Operationsbelow48°Fuidor38°Fambient 78
8.2 Operating with glycol (antifreeze) and with a set point above 48°F
or below 38°F ambient 80
8.3 Refrigerant pressure-temperature chart 81
8.4 Inhibited propylene glycol 82
8.5 Chiller capacity and derate chart 82
