TEMPUR EASE 4.0 - Quick Reference Guide; Control Box Overview; Electronics Overview

5
quick reference guide
Not to scale. For illustration purposes only. Read all instructions before beginning installation.
Power Cord
Wireless
Remote
Head Motor
Foot Motor
Control Box
Power Supply
Input
Power Cord
ELECTRONICS OVERVIEWCONTROL BOX OVERVIEW
If installing a split unit, see pages 10-11.
Power Cord
Multifunction
port
Foot Motor Head
Port Motor Port
Battery Backup Strap
